SCHNEIDER Resi9 XP Disjoncteur 16A Ph+N courbe D 3kA 230V - R9PFD616
- Réf. 123Elec : SCHR9PFD616
- Réf. Fabricant : R9PFD616
- Paiement 100 % sécurisé avec Monetico
- Large choix de modes de livraison
- Expédition offerte dès 250€ TTC d'achat
Besoin d’aide ?
À votre écoute au 04 81 12 00 80
ou par email
Produits complémentaires
-
SCHNEIDER Resi9 Tableau électrique nu 3 rangées 13 modules - R9H13403
- Réf. 123Elec : SCHR9H13403
- Réf. Fabricant : R9H13403
Présentation
SCHNEIDER Resi9 XP Disjoncteur 16A Ph+N courbe D 3kA 230V - R9PFD616Installez une protection optimale pour vos appareils en choisissant ce disjoncteur 16A dans votre tableau électrique.
- Afin de parer aux surcharges et courts-circuits, ce disjoncteur courbe D peut subir de fortes demandes en courant durant une courte période.
- Il est compatible avec les peignes horizontaux Schneider XP pour un raccordement simplifié.
- Idéal pour des applications telles que les clim, pompes et moteurs, ce disjoncteur est un produit de qualité, conforme aux normes, certifié NF et CE.
- Norme NF
- Norme CE
- Garantie 2 ans
Descriptif
Données techniques du disjoncteur courbe D :
- Pouvoir de coupure selon la NF EN 60898 : 3000A
- Courbe de déclenchement : D
- Connexion : à vis
- Nombre de module : 1
- Intensité : 16A
- Tension d'alimentation : 230V
- Pas de 9 mm : 2
- Blanc RAL 9003
- Degré de protection IP : IP40, IP20
- Température de fonctionnement : -25...40 °C
- Température ambiante pour le stockage : -40...80 °C
Avis clients
Aucun avis sur ce produit pour le moment
Questions & Réponses
Aucune question
Ces produits peuvent vous intéresser
-
EUROHM XL Air'métic Boite encastrement simple étanche à l'air D67 P50 - 52063
- Réf. 123Elec : EUR52063
- Réf. Fabricant : 52063
0,62 € TTC0,52 € HT -
EUROHM XL AIR'metic Boite encastrement double étanche à l'air P50 E71 - 52065
- Réf. 123Elec : EUR52065
- Réf. Fabricant : 52065
3,19 € TTC2,66 € HT -
EUROHM XL AIR'metic Boite encastrement triple étanche à l'air P50 E71 - 52067
- Réf. 123Elec : EUR52067
- Réf. Fabricant : 52067
4,45 € TTC3,71 € HT -
Nouveauté
SCHNEIDER Easy UPS Onduleur 4 prises 1 ph line-interactive 230V 800VA 450W - BVS800I-GR
- Réf. 123Elec : SCHBVS800I-GR
- Réf. Fabricant : BVS800I-GR
95,99 € TTC79,99 € HT -
SCHNEIDER Resi9 XP Télérupteur 16A 1NO monophasé - R9PCL116
- Réf. 123Elec : SCHR9PCL116
- Réf. Fabricant : R9PCL116
21,70 € TTC18,08 € HT -
SCHNEIDER Resi9 XP Disjoncteur 16A Ph+N courbe C 3kA 230V - R9PFC616
- Réf. 123Elec : SCHR9PFC616
- Réf. Fabricant : R9PFC616
9,70 € TTC8,08 € HT -
SCHNEIDER Resi9 XP Disjoncteur 20A Ph+N courbe C 3kA 230V - R9PFC620
- Réf. 123Elec : SCHR9PFC620
- Réf. Fabricant : R9PFC620
9,70 € TTC8,08 € HT -
SCHNEIDER Resi9 XP Disjoncteur 32A Ph+N courbe C 3kA 230V - R9PFC632
- Réf. 123Elec : SCHR9PFC632
- Réf. Fabricant : R9PFC632
12,50 € TTC10,42 € HT -
SCHNEIDER Resi9 XP Disjoncteur tétrapolaire 10A courbe C 3kA 400V - R9PFC710
- Réf. 123Elec : SCHR9PFC710
- Réf. Fabricant : R9PFC710
58,99 € TTC49,16 € HT -
SCHNEIDER Resi9 XP Disjoncteur tétrapolaire 16A courbe C 3kA 400V - R9PFC716
- Réf. 123Elec : SCHR9PFC716
- Réf. Fabricant : R9PFC716
54,50 € TTC45,42 € HT -
SCHNEIDER Resi9 XP Disjoncteur 20A Ph+N courbe D 3kA 230V - R9PFD620
- Réf. 123Elec : SCHR9PFD620
- Réf. Fabricant : R9PFD620
17,50 € TTC14,58 € HT -
SCHNEIDER Resi9 XP Parafoudre tétrapolaire autoprotégé type 2 10kA - R9PL3
- Réf. 123Elec : SCHR9PL3
- Réf. Fabricant : R9PL3
198,90 € TTC165,75 € HT -
SCHNEIDER Resi9 XP Interrupteur différentiel 63A 30mA type A 230V - R9PRA263
- Réf. 123Elec : SCHR9PRA263
- Réf. Fabricant : R9PRA263
89,20 € TTC74,33 € HT -
SCHNEIDER Resi9 XP Interrupteur différentiel 63A 30mA type AC 230V - R9PRC263
- Réf. 123Elec : SCHR9PRC263
- Réf. Fabricant : R9PRC263
74,40 € TTC62,00 € HT -
SCHNEIDER Resi9 XP Interrupteur différentiel tétrapolaire 63A 30mA type AC 4 modules 400V - R9PRC463
- Réf. 123Elec : SCHR9PRC463
- Réf. Fabricant : R9PRC463
189,90 € TTC158,25 € HT -
SCHNEIDER Resi9 XP Peigne d'alimentation électrique horizontal Phase Neutre 13 modules - R9PXH213
- Réf. 123Elec : SCHR9PXH213
- Réf. Fabricant : R9PXH213
6,50 € TTC5,42 € HT -
SCHNEIDER Resi9 XP Peigne d'alimentation électrique horizontal Phase Neutre 18 modules - R9PXH218
- Réf. 123Elec : SCHR9PXH218
- Réf. Fabricant : R9PXH218
9,50 € TTC7,92 € HT -
SCHNEIDER Resi9 XP Peigne vertical 2 rangées entraxe 125mm - R9PXV
- Réf. 123Elec : SCHR9PXV
- Réf. Fabricant : R9PXV
7,99 € TTC6,66 € HT -
Auto
SCHNEIDER Odace Prise de courant 2P+T anthracite - S540059
- Réf. 123Elec : SCHS540059
- Réf. Fabricant : S540059
3,60 € TTC3,00 € HT -
Auto
SCHNEIDER Odace Prise RJ45 grade 1 catégorie 6 anthracite - S540475
- Réf. 123Elec : SCHS540475
- Réf. Fabricant : S540475
13,90 € TTC11,58 € HT
Caractéristiques
Référence fabricant | R9PFD616 |
---|---|
Gencode EAN | 3606481160577 |
Marque | SCHNEIDER |
Gamme du produit | Schneider Resi9 XP à vis |
Intensité | 16A |
Type de courbe | Courbe D |
Pouvoir de coupure | 3kA |
Type de connexion | A vis |
Nombre de pôles | Monophasé 1P+N |
Emprise (en nombre de modules) | 1 |
Tension | 230V |
Nombre d'unité de vente | 1 |
Garantie | 2 ans |
Fabrication française | Non |
Label OFG (Origine France Garantie) | Non |
NF | Oui |
CE | Oui |
